WI-FI CONNECTIVITY AND DATA FAQS

Wi-Fi Hotspot operates through a mobile phone network. It will deliver a better data connection than a smartphone in the vehicle, but will not operate in areas where no mobile phone network exists.

At present Wi-Fi Hotspot is a linked feature with Connect/Connect Pro. Wi-Fi Hotspot can only be specified on vehicles fitted with Connect/Connect Pro.

Wi-Fi Hotspot operates on 3G/LTE networks.

Hotspot allows you to connect up to 8 devices including smartphones and tablets to your vehicle’s Internet connection.

Wi-Fi lets you connect to a Wi-Fi network, for example, your home network. It also allows you to connect to another device like a smartphone and share its data connection.

The strength of your mobile phone signal and data connection can be significantly reduced by the structure of the vehicle – metal reduces the transmission of radio waves.

When inserted, the SIM card located in your vehicle’s interface panel connects to the mobile network via a significantly larger, dedicated aerial on the outside of the vehicle. This helps to maintain a much stronger data connection with the network.

When you unlock the vehicle, Touch Pro initiates the process to connect to the mobile network. This can take up to 2 minutes – it’s similar to your mobile phone being turned on and connecting to its network. Once connected, a 3G icon will show in the upper corner of the Touchscreen. Touch Pro then downloads traffic information (if enabled) and syncs any places and destinations you may have saved using the Route Planner app or web portal. All connected features are now available.

The following features require an active internet connection:

• Real Time Traffic Information
• Share ETA, places and current location
• Online Routing
• Sync destinations to the vehicle and from the vehicle to the Route Planner app & website
• Live searches
• Fuel pricing (where supported)
• Vehicle parking availability (where supported)
• Street Level Imagery (where supported)
• Satellite Imagery (where supported)
• Live Apps (where supported)
• Wi-Fi Hotspot
• Web browser

At times, networks can be over capacity, or the signal strength too low to provide sufficiently high enough connection quality. This can result in a temporary loss of data.

Yes, a Micro SIM card with mobile data enabled is required to power the Connect Pro package. Insert your SIM card into the interface panel in the centre console storage compartment, and make sure you’ve enabled Mobile Data in the connectivity settings menu.

Go to the settings icon in any screen > All settings > Features > Connectivity > Mobile data on

You can also share your smartphone’s data connection by enabling the phone’s Internet Sharing, Personal Hotspot or Tethering feature. Please check with your mobile network provider to verify this feature is supported by your current phone tariff.

You need a "Data only SIM card". Sometimes these are called "Internet only SIM" or "Mobile broadband SIM". This will be a different SIM card to that fitted in your mobile phone. For Touch 17MY, the required SIM card is a 2FF standard SIM card, while for Touch Pro and Touch 18MY a 3FF micro SIM card is needed.

Yes, your SIM should have a data allowance for your Wi-Fi Hotspot to work. Voice only SIMs (as used on some mobile phones) cannot deliver data.

At present Jaguar Land Rover does not have a preferred data plan provider. You can obtain a “Data only SIM card” from a variety of sources. Data SIMs and plans are available from all major mobile service providers.

This depends on the mobile service provider and type of plan you have. Some providers offer "shared plans" where you can get an additional SIM for your Wi-Fi Hotspot and attach it to your shared plan. This means that your Wi-Fi Hotspot and your mobile phone consume the data from the shared allowance and you will get 1 bill.

EE, for example, offers a shared data plan as listed below:

EE: https://shop.ee.co.uk/sharer-details/samsung_galaxy_ace_3_black_and_sim

It will vary significantly based on the features you use, the frequency of use and the length of your journeys. As a very rough guide, typical usage consumes in the region of 100-500 MB of data per month.

These features use the greatest amount of data in the following order:

1. Wi-Fi Hotspot

2. Satellite Imagery

3. Street Level Imagery*

4. Real Time Traffic Information

5. Live Apps*

All other features consume far fewer data of approximately the same amount. Further examples are provided below:

FEATURE DATA CONSUMPTION

All other features consume far less data of approximately the same amount. Further examples are provided below:

MB= Mega Bytes

KB= Kilo Bytes

^{*where supported}

Yes, you can limit data usage to a specific number of megabytes per month, monitor the amount of data consumed, and disable roaming. Go to Settings > All settings > Features > Connectivity > Mobile settings

Yes, go to Settings > All settings > Features > Connectivity > Mobile settings

You can also enable specific roaming navigation features in the Navigation Settings menu.

1. Insert SIM card - Depending on your system, insert the SIM card into the slot market ‘SIM’ or ‘MICRO SIM’ in the centre console. Ensure the SIM is fully inserted with the gold connectors facing upwards.

2. Turn on mobile data - Once installed, go to the settings icon in any screen > All settings > Features > Connectivity > Mobile Data ON.

3. Establish connectivity - Your Touchscreen will now display a 4G or Wi-Fi icon. Please note, it may take up to two minutes for your screen to display ‘Reading SIM’ under ‘Mobile Data’.

This is most likely due to the auto-connect function for that device being disabled in your Bluetooth settings.

Up to 10 Bluetooth devices can be paired. One phone and one media playback device can be connected at the same time. If, however, your phone is connected as a phone and media playback device, a second device cannot be used simultaneously. The first device paired to Touch Pro will be designated your primary device, unless you change the settings.

Go to Settings > All settings > Features > Bluetooth > Paired devices > and click on the device you wish to change.

No, your synced contacts will only be visible when your phone is connected to the vehicle.

In the main phone screen select ‘Contacts’. Tap the search box at the top of the contacts screen to access the keyboard and start searching for your desired contact. As you type, the results list automatically updates. Click on the ‘x matches’ box to view options. To allow the largest number of contacts visible at one time the search box scrolls with the list allowing 5 instead of 4 items to be shown.

Alternatively, press the voice recognition button on the steering wheel and use a voice command to dial a number. For example:

‘Call David Smith’

‘Call David Smith Mobile’

‘Dial 01234987654’

If you’ve paired more than one phone to Touch Pro – tapping this icon enables you to switch to another device for placing/receiving calls.
